AQUARENA tube slides – all-round fun

The body slides can be designed as a black hole (completely black tube), colorful or fully themed, you decide.

A variety of light and sound effects and creative planning of the lines with straights, curves and jumps guarantee an exciting ride.

The tube slides of AQUARENA, are available in 2 different diameters, 825 mm, 1200 mm, (Bodyslide). With a diameter of 1500 mm, 2000 mm and 3000 mm, these are available mainly as Inner-Tube.

A particularly high fun factor is guaranteed when people speed down the slide at the same time in double or 3 person rafts. Long waiting times and big safety distances are not a problem, as the slide “swallows” up to 1000 riders an hour.

AQUARENA tube slides are available in 5 different diameters 825 mm, 1200 mm, (Bodyslide) 1500 mm, 2000 mm and 3000 mm, Inner-Tube.

Our tube slides RR0825 and RR1200 are seamless, without longitudinal flange, and are 100% watertight due to permanently fitting transitions, an integrated tongue and groove system and a special low-maintenance hard jointing.

The AQUARENA tube slide system complies with the European standard EN 1069 and all relevant regulations.

Insulation provides the operator with energy cost savings through thermal and sound insulation, as well as noise protection for residents.

Operational data

  • Length: typically (RR0825, RR1200) approx. 10 m, tpyically 40 – 100 m, (RR1500) approx. 80 – 200 m
  • Use: Body slide (RR0825, RR1200)
  • Minimum age: from 6 or 8 years
  • Speed: < = 8 m/s = 28.8 km/h (type 3), < 14 m/s (type 4)
  • Capacity: 150 persons/h (Bodyslide), 250-1000 persons/h (Innter-tubes)
  • TÜV certification in accordance with DIN EN 1069

Technical Data

  • Gradient: typically 10 – 12 % (type 3) 13 – 20 % (type 4)
  • Slide diameter: RR0825, RR1200
  • Landing: Plop exit (only Bodyslide), safety run-out, safety landing pool, shallow water run-out
  • Material: Fib
  • Starting height: 1.5 to > 15 m (Bodyslide); approx. 6 – >15 m (Inner-tubes)
  • Fiberglass, translucent or opaque, RAL color

Other/options
